UV 100W 400nm High Power LED for Medical Application

  • item#: G-100P45EP140UV-405
  • Retail price: 0
  • Wholesale Price: 65.00

  • Start from: 1 Unit(s)
  • This item is:

    Please Choose:


    Qty.Range(unit) Price(per unit) Discount
    2-4 0 1%
    5-9 0 1.5%
    10-19 0 2%
    20-49 0 3%
    50-99 0 4%
    100--max 0 5%
    * Discounts may vary based on options above
    Large Order:
  • 0
  • Quantity:



      Product Details

      • UV led is widely used in Health Care Equipment, Horiculture, Algea growing and Scientific Instruments. We can offer technology and Custom LED solutions support. If you have any special requirement, please contact us

      Package Dimension(mm):

      50W 405nm led Square substrate dimensions

      Square Substrate

      50W 405nm led Oval substrate dimensions

      Oval Substrate



      Key Features:


      • 99.99% gold wire bonding, 12mil

      • Red copper Subtrate

      • Chips: 100pcs*  45mil Epileds Chips

      • Connections: 10 in series, 10 in parallel

      • Applications: Agricultural lighting, Aquarium, horicultural lighting and other professional or commercial lighting.



      Absolute Maximum Ratings at Ta=25


      Item

      Symbol

      Absolute Maximum Rating

      Unit

      DC Forward Current

               IF

      3500

      mA

      Peak Forward Current

               IF

      5000

      mA

      Reverse Voltage

               VR

      5

      V

      Power Dissipation

               PD

      100

      W

      Electrostatic discharge

              ESD

      ±4500

      V

      Operation Temperature

              Topr

      -40~+80

      Storage Temperature

      Tstg

      -40~+100

      Lead Soldering Temperature

      Tsol

      Max.260℃ for 6 seconds Max.

      Life test

      ----

      1000 H  Luminous intensity weaken< 5%(3500mA,Ta=65℃);           50,000 H Luminous intensity weaken < 20% (3500mA,Ta=65℃);





      Electrical Optical Characteristics at Ta=25



      Parameter

      Symbol

      Min.

      Typ.

      Max.

      Unit

      Test Condition

      Forward Voltage

      VF

      30.0

      ---

      34.0

      V

      IF=3500mA

      Reverse Current

      IR

      ---

      ---

      50

        uA

                     VR=5V

      50% Power Angle

      2θ1/2

      ---

      140

      ---

           Deg.

      IF=3500mA

      Radiant Power

      Po

      30000

      ---

      38000

      mW

      IF=3500mA

      Peak Wavelength

      λp

      400

      405

      410

      nm

      IF=3500mA
