5W Blue 460nm High Power LED for Plant Grow light on star PCB

  • item#: G-5P45V140A1-B1
  • Retail price: 0
  • Wholesale Price: 3.00

  • Start from: 10 Unit(s)
  • This item is:

    Qty.Range(unit) Price(per unit) Discount
    Large Order:
  • 0
  • Quantity:



      Product Details

      Package Dimension(mm):

      460nm Blue LED 5W package dimension

      20mm Star LED PCB

      Key Features:


      • 99.99% gold wire bonding, 1.2mil

      • Red copper Subtrate

      • Chips: 4pcs*  45mil Epileds Chips (2 in series, 2 in parallel)

      • Type: Emitter on Star PCB or only the emitter

      • Beam Angle:  60 degree and 120 degree are available

      • Applications: Agricultural lighting, horicultural lighting, health care instrument and other professional or commercial lighting.

      • Extra HEATSINK is required for the LEDs.



      Absolute Maximum Ratings at Ta=25



      Item

      Symbol

      Absolute Maximum Rating

      Unit

      DC Forward Current

      IF

      700

      mA

      Peak Forward Current

      IF

      1000

      mA

      Reverse Voltage

      VR

      5

      V

      Power Dissipation

      PD

      5000

      mW

      Electrostatic discharge

      ESD

      ±4500

      V

      Operation Temperature

      Topr

      -40~+80

      Storage Temperature

      Tstg

      -40~+100

      Lead Soldering Temperature

      Tsol

      Max.260 for 6 seconds Max.

      Life test

      ----

      1000H Luminous intensity weaken< 5%(700mA,Ta=65℃);        50,000H Luminous intensity weaken < 20% (700mA,Ta=65℃);



       Electrical Optical Characteristics at Ta=25



      Parameter

      Symbol

      Min.

      Typ.

      Max.

      Unit

      Test Condition

      Forward Voltage

      VF

      6.0

      ---

      7.0

      V

      If=700mA

      Reverse Current

      IR

      ---

      ---

      50

      uA

      VR=5V

      50% Power Angle

      2θ1/2

      ---

      140

      ---

          Deg.

      IF=700mA

      Luminous Flux

              Φ

      60

      ---

      80

      lm

      IF=700mA

      Peak Wavelength

      λp

      455

      460

      465

      nm

      IF=700mA
