30W IR 810nm High Power LED

  • item#: G-30P42DR140A1-IR
  • Retail price: 0
  • Wholesale Price: 40.00

  • Start from: 2 Unit(s)
  • This item is:

    Please Choose:


    Qty.Range(unit) Price(per unit) Discount
    40--max 0 37.44%
    * Discounts may vary based on options above
    Large Order:
  • 0
  • Quantity:



      Product Details

      The available IR wavelengths from 700nm, 710nm, 720nm, 730nm, 740nm, 750nm, 760nm, 780nm, 790nm, 800nm, 810nm, 830nm, 850nm, 860nm, 880nm, 890nm, 910nm, 940nm, 960nm, 970nm, 980nm, 1050nm. We offer technology and Custom LED solutions support, If you have any special requirements out of store, please contact us.


      Package Dimension(mm):



      30W IR 810nm LED square substrate package dimension

      Square Substrate

      30W IR 810nm led Oval Round substrate package dimension

      Oval Substrate



       Key Features:


      • 99.99% gold wire bonding, 1.2mil

      • Chips: 30pcs 42mil Epileds

      • Type: Square and oval Substrate

      • Applications: mainly used for Iris scanner, surveilance system, CCTV camera, night and machine vistion, medical and other professional equipment

      • Extra HEATSINK is required for the LEDs.



      Absolute Maximum Ratings at Ta=25



      Item

      Symbol

      Absolute Maximum Rating

      Unit

      DC Forward Current

      IF

      1050

      mA

      Peak Forward Current

      IF

      1200

      mA

      Reverse Voltage

      VR

      5

      V

      Power Dissipation

      PD

      30

      W

      Electrostatic discharge

      ESD

      ±4500

      V

      Operation Temperature

      Topr

      -40~+80

      Storage Temperature

      Tstg

      -40~+100

      Lead Soldering Temperature

      Tsol

      Max.260 for 6 seconds Max.

      Life test

      ----

      1000 H  Luminous intensity weaken< 5%(1050mA,Ta=65℃);        50,000 H Luminous intensity weaken < 20% (1050mA,Ta=65℃);



      Electrical Optical Characteristics at Ta=25



      Parameter

      Symbol

      Min.

      Typ.

      Max.

      Unit

      Test Condition

      Forward Voltage

      VF

      14.0

      ---

      16.0

      V

      If=1050mA

      Reverse Current

      IR

      ---

      ---

      50

      uA

      VR=5V

      50% Power Angle

      2θ1/2

      ---

      140

      ---

          Deg.

      IF=1050mA

      Radiant Power

      Po

      4000

      ---

      5000

      mW

      IF=1050mA

      Peak Wavelength

      λp

      ---

      810

      ---

      nm

      IF=1050mA
