200W UV 395nm High Power LED

  • item#: G-200P45EP140UV-390
  • Retail price: 0
  • Wholesale Price: 116.00

  • Start from: 1 Unit(s)
  • This item is:

    Qty.Range(unit) Price(per unit) Discount
    Large Order:
  • 0
  • Quantity:



      Product Details

      • UV led is widely used in Health Care Equipment, Horiculture, Algea growing and Scientific Instruments. We can offer technology and Custom LED solutions support. If you have any special requirement, please contact us

      Package Dimension(mm):

      200W 395nm LED dimensions

      Key Features:


      • 99.99% gold wire bonding, 12mil

      • Red copper Subtrate

      • Chips: 200pcs*  45mil Epileds Chips

      • Connections: 20 in series, 10 in parallel

      • Applications: Agricultural lighting, Aquarium, horicultural lighting and other professional or commercial lighting.



      Absolute Maximum Ratings at Ta=25


      Item

      Symbol

      Absolute Maximum Rating

      Unit

      DC Forward Current

      IF

      3500

      mA

      Peak Forward Current

      IF

      4000

      mA

      Reverse Voltage

               VR

      5

      V

      Power Dissipation

               PD

      200

      W

      Electrostatic discharge

               ESD

      ±4500

      V

      Operation Temperature

               Topr

      -40~+80

      Storage Temperature

       Tstg

      -40~+100

      Lead Soldering Temperature

       Tsol

      Max.260℃ for 6 seconds Max.

      Life test

      ----

      1000 H  Luminous intensity weaken< 5%(3500mA,Ta=65℃);           50,000 H Luminous intensity weaken < 20% (3500mA,Ta=65℃);





      Electrical Optical Characteristics at Ta=25



      Parameter

      Symbol

      Min.

      Typ.

      Max.

      Unit

      Test Condition

      Forward Voltage

      VF

      60.0

      ---

      68.00

      V

      IF=3500mA

      Reverse Current

      IR

      ---

      ---

      50

        uA

                     VR=5V

      50% Power Angle

      2θ1/2

      ---

      140

      ---

           Deg.

      IF=3500mA

      Radiant Power

      Po

      65000

      ---

      75000

      mW

      IF=3500mA

      Peak Wavelength

      λp

      ---

      390

      395

      nm

      IF=3500mA
