100W IR 980nm High Power LED

  • item#: G-100P42GR140A1-980IR
  • Retail price: 0
  • Wholesale Price: 112.00

  • Start from: 1 Unit(s)
  • This item is:

    Please Choose:


    Qty.Range(unit) Price(per unit) Discount
    * Discounts may vary based on options above
    Large Order:
  • 0
  • Quantity:



      Product Details

      The available IR wavelengths from 700nm, 710nm, 720nm, 730nm, 740nm, 750nm, 760nm, 780nm, 790nm, 800nm, 810nm, 830nm, 850nm, 860nm, 880nm, 890nm, 910nm, 940nm, 960nm, 970nm, 980nm, 1050nm. We offer technology and Custom LED solutions support, If you have any special requirements out of store, please contact us.


      Package Dimension(mm):



      50W IR 810nm LED square substrate package dimension

      Square Substrate

      50W IR 810nm led Oval Round substrate package dimension

      Oval Substrate



       Key Features:


      • 99.99% gold wire bonding, 1.2mil

      • Chips: 100pcs 42mil Epileds

      • Substrate Type: Square and Oval

      • Applications: mainly used for Iris scanner, surveilance system, CCTV camera, night and machine vistion, medical and other professional equipment

      • Extra HEATSINK is required for the LEDs.



      Absolute Maximum Ratings at Ta=25



      Item

      Symbol

      Absolute Maximum Rating

      Unit

      DC Forward Current

      IF

      3500

      mA

      Peak Forward Current

      IF

      4000

      mA

      Reverse Voltage

      VR

      5

      V

      Power Dissipation

      PD

      100

      W

      Electrostatic discharge

      ESD

      ±4500

      V

      Operation Temperature

      Topr

      -40~+80

      Storage Temperature

      Tstg

      -40~+100

      Lead Soldering Temperature

      Tsol

      Max.260 for 6 seconds Max.

      Life test

      ----

      1000 H  Luminous intensity weaken< 5%(3500mA,Ta=65℃);        50,000 H Luminous intensity weaken < 20% (3500mA,Ta=65℃);



      Electrical Optical Characteristics at Ta=25



      Parameter

      Symbol

      Min.

      Typ.

      Max.

      Unit

      Test Condition

      Forward Voltage

      VF

      11.0

      13.0

      14.0

      V

      If=3500mA

      Reverse Current

      IR

      ---

      ---

      50

      uA

      VR=5V

      50% Power Angle

      2θ1/2

      ---

      140

      ---

          Deg.

      IF=3500mA

      Radiant Power

      Po

      5000

      ---

      6000

      mW

      IF=3500mA

      Peak Wavelength

       λp

      975

      980

      985

      nm

      IF=3500mA
